1.3.2 User Configurable Single-Use Temp USB PDF Data Logger w/ BT (10 Pieces)

Regular price
$196.89
Regular price
Sale price
$196.89
  • Internal sensor & Self-generated PDF report
  • Measurement range: -30°C to 70°C
  • Accuracy: ±0.5°C (0 to 60°C), ±1.0 °C (else)
  • Blue tooth & Mobile APP & USB
  • Storage 32000 records
  • LED status and alarm indication
  • Sampling interval: user configurable from 1 to 225 mins
  • Run days: dependent on sampling interval
  • Protection Class: IP67 & Certification: CE, ROHS
  • Batch calibration report included with each pack
  • Test points: -29°C, -18°C, 5°C, 13°C, 30°C and 69°C on the report to cover the range
Sku: 32200

Package: 10 pieces

Shipping: 2-3 weeks

1.3.2 User Configurable Single-Use Temp USB PDF Data Logger w/ BT (10 Pieces)
1.3.2 User Configurable Single-Use Temp USB PDF Data Logger w/ BT (10 Pieces)
  • Description
  • Specifications
  • Manual and Resources

Accurate measurement & easy use data logging
This temperature data logger has an accuracy ±0.5°C (0 to 60°C) and ±1.0 °C (else) within the wide temperature range of -30°C to 70°C. No special software or driver is required for set-up or download data. Press the start button to begin logging temperature data with a pre-set delay before logging begins. After the logging is done, plug logger into any PC USB port and a PDF report is automatically generated containing data summary, graph, and user-initiated marks.
This PDF file autogenerated functionality and non-need for any other special software or driver make them widely used in cold chain applications.
Up to 8 marker points
This data logger supports data marking up to 8 points. In the process of logging, the user can use the button to mark the data.
IP67 protection & compact size
The IP67 water-resistant protection and compact, lightweight size ensures its reliability even when shipped in packaging that contains cold packs or ice, and in damp environments. To maintain IP67 protection, keep the logger in its protective plastic receptacle until data retrieval.
Bluetooth communication with Mobile app & User configurable
This self-contained, single-use temperature data logger is Bluetooth-enabled and can be easily connected to mobile devices through a free App. Users can install the App by scanning the QR code on the logger or searching for "Temp Record Label" on their device's App Store. Within a 50-feet distance, the App provides access to settings configuration, operation reports for review or download.
Applications
This compact, lightweight temperature data logger with IP67 protection can be a reliable device for monitoring the real-time temperature conditions of pharmaceuticals, food, and other temperature-sensitive products during transportation or storage. It’s designed with our customers in mind to allow for easy placement inside any package.
Calibration reports
A batch calibration certificate is provided with each pack to assure accuracy from an ISO/IEC 17025:2017 conforming calibration laboratory and indicates traceability of measurements to the SI units through NIST.
More categories
Additionally, we offer two other categories of custom loggers: one with preset alarm values and logging intervals to choose from, and the other can be customized by the user to meet specific requirements. If you have any inquiries or requests, please don't hesitate to reach out to us. We are more than happy to provide answers and assist in creating a customized setup to fulfill your specific needs.

Probe type

Internal sensor

Unit

°C, °F

Resolution

0.01°C

Measurement range

-30°C to 70°C

Accuracy

±0.5°C (0 to 60°C), ±1.0°C (else)

Report generation

Automatic pdf report generation

Data storage capacity

32000

Sampling interval

User configurable from 1 to 225 mins

Run days

Dependent on sampling interval, max 180 days

High and low alarm values

User configurable from -30°C to 70°C

Alarm delay

User configurable from 0 to 65535 minutes

Alarm type

Single time or cumulative, user configurable

Start delay

User configurable from 0 to 65535 mins

Start recording mode

Press and hold the button for 5 secs

Stop recording mode

Automatic stop when the memory is full

When connected to a computer

Operation/storage temperature

-30°C to 70°C

Communication interface

USB 2.0, Blue tooth with mobile app

PC Software

Mobile app to configure, read and download data

No software needed for pdf file generation

Power supply

CR2450 Button Cell

Shelf life

2 years

Protection Class

IP67

Dimensions/weight

73mm*30mm*7mm/16g

Certification and standards

CE | ROHS

Calibration report

Batch calibration report included with each pack

Test points

-29°C, -18°C, 5°C, 13°C, 30°C and 69°C covering the range
