6.6 Multi-Use Temp+RH PDF Data Logger w/Bluetooth

Regular price
$169.89
Regular price
Sale price
$169.89
  • Internal RH+T sensor & Self-generated PDF report
  • Measurement range -20°C to 70°C & 0.1%rh to 99.9%rh
  • Accuracy: Basic T: ±0.3°C, RH: ±3.0%rh (20%rh to 80%rh), ±4.0%rh (else)
    • Optional T: ±0.2°C, RH: ±2.0%rh (20%rh to 80%rh), ±3.0%rh (else)
  • Bluetooth & Mobile app & USB
  • PC software for configuration & data analysis & calibration
  • Large storage capacity up to 25920 records
  • Non-volatile memory & No data loss when power off
  • Long standby time & High/low alarm settings
  • CR2450 non-rechargeable lithium battery, user replaceable
  • Protection Class: IP40 & Certification: CE, ROHS, EN12830
  • Calibration report included with each unit
  • Test points: 20%rh, 50%rh and 80%rh @ 25°C and 25°C on the report
Accuracy: T: ±0.2°C ; RH: ±2.0%rh (20%rh to 80%rh) ; ±3.0%rh (else)
Sku: 36324-2

Shipping: 2-3 weeks

6.6 Multi-Use Temp+RH PDF Data Logger w/Bluetooth
6.6 Multi-Use Temp+RH PDF Data Logger w/Bluetooth
  • Description
  • Specifications
  • Manual and Resources

Data logging user configurable

This temperature and humidity datalogger can be configurated through PoChain software (available for download under the software tab) or mobile app BoChain (downloadable from the App Store). Once configured, simply press the button to begin logging immediately or schedule a delay either on software settings or through the BoChain app via Bluetooth connection.

Data analysis & Data Export 

After the data logging is completed, connect the data logger to a computer with installed PoChain software, the software allows for efficient and comprehensive data analysis and exportation in various forms such as xls, csv, pdf, txt, and cin, to a designated location on the user's computer.

3 marker points  

This data logger supports data marking 3 points. In the process of logging, the user can use the key to enter mark mode (MK), then press the key to mark the data.

Re-calibratable assures long time use in tolerance

Each unit is shipped with a calibration report to assure accuracy from an ISO/IEC 17025:2017 conforming calibration laboratory and indicates traceability of measurements to the SI units through NIST. It can be recalibrated by PoChain software with up to 6 points calibration by any lab with calibration capability (not recommended to be done by user) or our lab as well.  

Application

This temperature and humidity logger is a good choice for a wide range of applications including transportation, storage, production, laboratory, museum, greenhouse, and others.

Probe type

Internal RH+T sensor

Unit

°C, °F & %rh

Resolution

0.1°C & 0.1%rh

Measurement range

-20°C to 70°C & 0.1%rh to 99.9%rh

Accuracy

Basic T: ±0.3°C, RH: ±3.0%rh (20%rh to 80%rh), ±4.0%rh (else)
Optional: T: ±0.2°C, RH: ±2.0%rh (20%rh to 80%rh), ±3.0%rh (else)

File format

pdf, txt, csv, xls, cin

Data storage capacity

25920 records

Memory

Non-volatile memory, no data loss when power off

Sampling interval

User configurable from 10 seconds to 18 hours

High and low alarm values

User configurable

Start recording mode

Press the button or by mobile app

Stop recording mode

Press the button or by mobile app

When connected to a computer

Operation temperature

-20°C to 70°C

Storage temperature

-20°C to 70°C (no battery)

Communication interface

USB 2.0, Bluetooth 4.2

PC Software

PoChain website downloadable & BoChain downloadable from mobile app store

Power supply

CR2450 lithium battery, user replaceable

Battery life

About 1 year @ 15 minutes sampling interval, 25°C

Protection Class

IP40

Shell material

POM

Dimensions/weight

φ50mm*19mm/34g

Certification and standards

CE | ROHS | EN12830

Calibration

Max. 6 points calibration by software

Calibration report

Calibration report included with each unit

Test points

20%rh, 50%rh and 80%rh @ 25°C and 25°C on the report
