3.1.5 -40°C to 125°C Multi-Use Temp USB PDF Data Logger Alloy Shell
- Regular price
- $217.99
- Regular price
-
- Sale price
- $217.99
- Unit price
- per
- Internal sensor &Self-generated PDF report
- Measurement range -40°C to 125°C
- Accuracy: Basic ±0.2°C
- Optional ±0.15°C
- Rigid alloy material shell
- PC software for configuration & data analysis & calibration
- Storage capacity of 25920 records
- Non-volatile memory, no data loss when power off
- Low power consumption and long standby time
- Sampling interval: 1 seconds to 24 hours
- 3.6V 2/3 AA high temperature lithium battery, user replaceable
- Protection Class: IP67 & Certification: CE, ROHS, EN12830
- Calibration report included with each unit
- Test points: -39, 0, 50, 75 and 124°C on the report covering the range
Shipping: 2-3 weeks
Couldn't load pickup availability
Have a question?
Notified by email when this product becomes available
- Description
- Specifications
- Manual and Resources
Multi-use, configurable
The special alloyed shell makes this multi-use data logger very rigid with high mechanical strength, temperature resistance and IP67 protection class. The quality of its internal sensor and electronics assures an accuracy of ±0.2°C (optional ±0.15°C) over its range, -40°C to 125°C.
It can be easily configured using the PoChain software (available for download on the website) and it starts logging immediately or with a delay, depending on your preferred configuration.
Data analysis & Data Export
Once connected to a computer with installed PoChain software, this data logger allows for efficient and comprehensive data analysis and exportation in various forms such as xls, csv, pdf, txt, and cin, to a designated location on the user's computer.
Re-calibratable assures long time use in tolerance
Each unit is shipped with a calibration report to assure accuracy from an ISO/IEC 17025:2017 conforming calibration laboratory and indicates traceability of measurements to the SI units through NIST. It can be recalibrated using the PoChain software with up to 6 points calibration by any lab with calibration capability (not recommended to be done by user) or our lab as well.
Application
This data logger responds to the test environment’s temperature very fast from its alloy shell. It is an ideal selection for low and high temperature applications, such as autoclaves, chambers, etc.
|
Probe type |
Internal sensor |
|
Unit |
°C, °F |
|
Resolution |
0.1°C |
|
Measurement range |
-40°C to 125°C |
|
Accuracy |
Basic ±0.2°C, Optional ±0.15°C |
|
Report form |
Tamper-Proof, encrypted PDF data only accessible to authorized users |
|
Export file formats |
pdf, txt, csv, xls, cin |
|
Data storage capacity |
25920 records |
|
Memory |
Non-volatile memory, no data loss when power off |
|
LED indicator on |
Keeping on for 3 minutes after setup |
|
LED indication |
Single flash every 5 secs: recording Double flash every 5 secs: non-recording |
|
Sampling interval |
User configurable from 1s to 24 hrs |
|
High and low alarm values |
User configurable from -40°C to 125°C |
|
Alarm delay |
User configurable from 0 to 960 mins |
|
Alarm type |
Single time or cumulative, user configurable |
|
Start recording mode |
Start on a pre-set time by software |
|
Stop recording mode |
Automatic stop when the memory is full; When connected to a computer |
|
Real-time data logging |
Available by software EasyDataPro (-40°C to 85°C) |
|
Operation temperature |
-40°C to 125°C |
|
Storage temperature |
-40°C to 85°C |
|
Communication interface |
USB 2.0 |
|
PC Software |
Software PoChain (Windows 7/8/Vista/10 32/64bits) website downloadable |
|
Power supply |
3.6V 2/3 AA high temperature battery, user replaceable |
|
Battery life |
2 years @ 15 minutes sampling interval, 25°C |
|
Protection Class |
IP67 |
|
Shell material |
Special alloy |
|
Dimensions/weight |
φ18mm*115mm/95g |
|
Certification and standards |
CE | ROHS | EN12830 |
|
Calibration |
Max. 6 points calibration by software |
|
Calibration report |
Calibration report included with each unit |
|
Test points |
-39, 0, 50, 75 and 124°C on the report covering the range |
